SR3308

Reshape your scanner, make better business decisons. Meet our latest 1D/2D barcode scanner 3308. The very comprehensive and fast imagine scanning help your business move on fast and safe.
1D Handheld Barcode Scanner

Highlight

Stable

5 millions times of scan press

2D QR Code Scanner

Precise

Scan distance up to 400mm
Scan light density within 3mil

2D QR Code Scanner
2D Handheld QR Code Scanner

Solid

1.5m drop resistance

1D QR Code Scanner

Versatile

Recognizes 80 countries’ keyboard languages

1D QR Code Scanner
Specifications
Sensor CMOS
Pixels 640*480
Illumination White light
Aiming Red light
Symbologies 2D: PDF417, QR Code, Data Matrix, HanXin, Maxicode , Postal Codes etc.
1D: Code128, UCC/EAN-1 28, AlM128, EAN-8, EAN-1 3, ISBN/ISSN,UPC-E,UPCA, Interleaved 2 of 5, ITF-6, ITF-4, Matrix 2 of 5, lndustriaI 25, Standard 25, Code39, Codabar, Code 93, Code11, Plessey, MSI-Plessey, RSS-14. RSS-Limited. RSS-Expand etc.
Recognizing Precision ≥4mil
Depth of Field ENA-13:30-200mm
QR(20mil): 20-150mm
Barcode Sensibility Pitch±45º
Tilt360º
Skew±45º
Field of view Horizontal: 40°, vertical: 30°
Relative Contrast Value ≥25%
Dimension(mm) 100*68*165
Weight 135g
Interface Type RJ-45 crystal head
Housing Material PC+ABS
Notification Buzzer, LED light
Interfaces RS-232 serial interface
USB keyboard
USB virtual serial interface
Trigger Method Keyboard recognition
Induction recognition
Continuous recognition
Operating Voltage 5VDC±10%
Operating Current Standby: 50mA Working: 230mA
Working Temperature -20--50°C
Storage Temperature -40--70°C
Humidity 5% to 95% (non-condensing)
ESD ±4Kv Contact Discharge ±8Kv Air Discharge
Drop 1.2m
Environmental Sealing IP42
Certifications CE FCC
